UNS N06625 Inconel 625 Seamless Yeeb Nkab

UNS N06625 Inconel 625 Seamless Pipe
UNS N06625 Inconel 625 Seamless Pipe
UNS N06625 Inconel 625 Seamless Pipe
UNS N06625 Inconel 625 Seamless Pipe

UNS N06625 Inconel 625 Seamless Yeeb Nkab

Inconel 625 Yeeb Nkab yog nickel chromium super alloy yeeb nkab uas yog tsim los ntawm 58% nickel, 20% chromium, carbon, manganese, silicon, hlau, sulfur, txhuas thiab titanium nyob rau hauv muaj pes tsawg leeg. Cov kav dej yog cov tshuaj tiv thaiv corrosion heev. GNEE Steel yog cov chaw tsim khoom thiab cov chaw muag khoom ntawm Inconel 625 Yeeb thiab raj. Cov khoom muaj 517MPa yam tsawg kawg nkaus lub zog thiab 930MPa lub zog tensile yam tsawg kawg nkaus.

Xa kev nug

Tsham tam sim no

Raws li tus neeg muag khoom thiab chaw tsim khoom nyob rau hauv Suav teb, GNEE Steel muab tus nqi -nickel zoo- raws li cov khoom siv alloy.

Xa E-mail:ss@gneesteel.com
Tel:+8615824687445

Khoom Taw qhia

Inconel 625 Seamless Yeeb Nkablos raws li qhov tshwj xeeb ASTM B167 lossis ASME SB 167. Cov khoom siv muaj zog tensile siab ntawm 940MPa thiab siab yield zog ntawm 430MPa. Nws kuj tseem muaj qhov kub ntawm qhov kub siab tshaj 1400 degrees Celsius nrog kev ua haujlwm kub txog li 982 degrees Celsius. GNEE Steel yog cov chaw tsim khoom thiab cov chaw muag khoom ntawm Alloy 625 Seamless Pipe khoom.

Inconel 625 Pipe Standard Sizes Thiab Schedule Specifications

Lub npe lag luam	Inconel 625 Tube thiab Tube
Specifications:	ASTM B161, B517, B163 / ASME SB161, SB517, SB163
Txuj	ASTM, ASME thiab API
Loj	15mm NB rau 150mm NB (1/2 "mus rau 6"), 7" (193.7mm OD txog 20" 508mm OD)
Sab nraud	1.250" - 6. 000" (30-150mm)
Phab ntsa Range	0.095″ – 1.000″ (.2.5-25mm)
Teem caij	TSW 20 SCH 30 SCH 40 STD SCH 80 SCH 60 SCH 80 SCH 120 SCH 140 SCH 160 XXS
Hom	Seamless / ERW / Welded / Fabricated / LSAW Pipes
Ntev	Ib qho Random, Ob Chav Random & Txiav Ntev lossis Raws li tus neeg siv khoom xav tau (siab tshaj li 7 meters)
Daim ntawv	Round Pipes/Tubes, Square Pipes/Tubes, Rectangular Pipes/Tubes, Coiled Tubes, "U" Shape, Pan Cake Coils, Hydraulic Tube

Alloy Seamless Pipe

Cov khoom tseem ceeb thiab cov yam ntxwv ntawm Inconel 625 Seamless Tube

Inconel 625 seamless raj muaj ntau yam ntawm cov khoom tseem ceeb thiab cov yam ntxwv uas ua rau nws siv dav hauv ntau yam lag luam. Ib qho ntawm nws cov cwj pwm tseem ceeb yog nws qhov ua tau zoo heev rau qhov kub thiab txias, ua rau nws tsim nyog rau kev siv hauv qhov chaw siab-kub. Nws tuaj yeem tiv taus qhov kub thiab txias txog li 2,{3}} degree F (1,093 degree) yam tsis muaj qhov tsis zoo ntawm cov khoom siv kho tshuab, uas tso cai rau nws ua tau raws li qhov xav tau.

Lwm cov cuab yeej tshwj xeeb ntawm Inconel 625 seamless raj yog nws qhov tshwj xeeb corrosion kuj. Nws tiv taus oxidizing thiab txo qhov chaw, nrog rau ntau yam tshuaj corrosive, acids, thiab alkalis. Qhov kev tiv thaiv corrosion no txuas mus rau chloride-induced stress corrosion cracking thiab pitting, ua rau nws yog ib qho kev xaiv txhim khu kev qha rau kev siv hauv marine thiab offshore ib puag ncig.
