Alloy 625 yog npib tsib xee-chromium-molybdenum cov khoom ua kom muaj zog alloy nrog cov tshuaj nominal ntawm 61% npib tsib xee, 22% chromium, thiab 9% molybdenum. Nws feem ntau raug xa mus los ntawm lub npe lag luam Inconel® 625 thiab lub npe thoob ntiaj teb UNS N06625. Alloy 625 muab superior corrosion kuj nyob rau hauv ib puag ncig nruj ua ke nrog zoo heev zog thiab weldability.
Xa kev nug
Tsham tam sim no
Raws li tus neeg muag khoom thiab chaw tsim khoom nyob rau hauv Suav teb, GNEE Steel muab tus nqi -nickel zoo- raws li cov khoom siv alloy.
- Xa E-mail:ss@gneesteel.com
- Tel:+8615824687445
Khoom Taw qhia
Ib 625(UNS npe N06625) yog nickel-based superalloy uas muaj lub zog muaj zog thiab ua haujlwm rau qhov kub siab. Nws kuj ua tau zoo heev tiv thaiv corrosion thiab oxidation. Nws muaj peev xwm tiv taus kev ntxhov siab thiab ntau qhov kub thiab txias, ob qho tib si hauv thiab tawm hauv dej, nrog rau muaj peev xwm tiv taus corrosion thaum raug rau ib puag ncig acidic heev ua rau nws xaiv haum rau kev siv nuclear thiab marine.
Tshuaj muaj pes tsawg leeg:
| Cr | Ni | Mo | Co | Nb (+Ta) | Ti | W | Cu | C | Mn | N | Si | P | S | Fe | Al | |
| Min | 20.00 | 58.00 | 8.00 | 3.15 | ||||||||||||
| Max | 23.00 | 10.00 | 1.00 | 4.15 | 0.40 | 0.10 | 0.50 | 0.50 | 0.015 | 0.015 | 5.00 | 0.40 |
Mechanical Properties:
| Bars mus txog thiab suav nrog 4 "inch lossis ntu | Bars saum 4 "inch diameter los yog seem | |||
| 0.2% Pov Thawj Kev Nyuaj Siab | 415 N / hli2 | 60 ksg | 345 N / mm2 | 50 ksg |
| Tensile zog | 830 N / hli2 | 120 ksg | 760 N / mm2 | 110 ksg |
| Elongation, 5.65√S0thiab 4D | 30% | 25% | ||
| Kev txo qis ntawm cheeb tsam | 35% | 35% | ||
| Hardness (Brinell) | ||||
Lub cev muaj zog:
| Qhov ceev (Kg.m-1) | 84.4 |
| Sib nqus permeability (20 degree) | <1.001 |
| Curie Kub (degree) | -196 |
| Young's Modulus (N/mm2) | 207.5 |
| Cov cua kub tshwj xeeb, 20 degree (J / (gK)) | 410 |
| Kev tiv thaiv hluav taws xob tshwj xeeb, 20 degree (Ω-m) | 0.0129 |
| Thermal conductivity, 20 degree (W / (mK)) | 9.9 |
| Lub ntsiab lus coefficient ntawm thermal expansion, 20-100 degree (/K) | 12.8 x 10-6 |
Nickel Inconel Alloy 625 Cov khoom muaj xws li:
- Lub zog vim qhov sib ntxiv ntawm molybdenum thiab niobium
- Zoo thermal qaug zog lub zog
- Resistance rau oxidation thiab ntau yam corrosive ntsiab
- Yooj yim ntawm kev sib koom los ntawm txhua hom vuam
- Kov ntau qhov kub thiab txias los ntawm cryogenic mus rau 1800 degree F (982 degree)
Nickel Alloy 625 Daim ntawv thov suav nrog
- Nuclear reactor-cores thiab tswj-qws Cheebtsam
- Hlau hlua rau cables thiab hniav ntawm Naval crafts xws li gunboats thiab subs
- Cov khoom siv Oceanographic
- Rings thiab tubing rau kev tswj ib puag ncig
- Raws li ASME code rau Boiler thiab Pressure Vessels
