Tom ntej: Nickel Alloy Inconel 617

Nickel alloy Inconel 617 muaj nickel-chromium-cobalt thiab - molybdenum. Cov ntsiab lus no ua rau nickel alloy Inconel 617 tiv taus oxidation thiab carburization.

Xa kev nug

Tsham tam sim no

Raws li tus neeg muag khoom thiab chaw tsim khoom nyob rau hauv Suav teb, GNEE Steel muab tus nqi -nickel zoo- raws li cov khoom siv alloy.

Xa E-mail:ss@gneesteel.com
Tel:+8615824687445

Khoom Taw qhia

Nickel alloy 617 /Ib 617(UNS N06617) yog npib tsib xee-chromium-cobalt-molybdenum alloy nrog kev sib xyaw tshwj xeeb ntawm lub zog kub kub thiab oxidation tsis kam. Cov ntsiab lus siab nickel thiab chromium ua rau cov hlau 617 tiv taus ntau yam ntawm ob qho tib si txo thiab oxidising ib puag ncig, thaum lub txhuas nrog chromium muab oxidation tsis kam ntawm qhov kub thiab txias. Cov ntsiab lus nrog molybdenum pab kom cov hlau tiv taus ntau qhov chaw ntub dej corrosive.

Cov kev txwv tshuaj muaj pes tsawg leeg ntawm Inconel alloy 617 yog teev nyob rau hauv cov lus hauv qab no:

Qhov hnyav%

alloy 617

44.5
min

20 - 24

8 - 10

3 max

0.15
max

0.05 - 0.15

1 max

0.006

0.50
max

0.60
max

10 - 15

0.15 max

1 max

0.8 -1 .5

UNS N06617/Alloy 617 Mechanical Properties

Cov ntaub ntawv thiab cov xwm txheej		Yield zog		Tensile zog		Elongation%	Kev txo qis ntawm cheeb tsam	Hardness, BHN
Cov ntaub ntawv thiab cov xwm txheej		KSI	MPa	KSI	MPa	Elongation%	Kev txo qis ntawm cheeb tsam	Hardness, BHN
Alloy 617 Bars	Kev daws Annealed	46.1	318	111.5	769	56	50	181
Alloy 617 Daim	Kev daws Annealed	50.9	351	109.5	755	58	-	173
Alloy 617 Phaj	Kev daws Annealed	46.7	322	106.5	734	62	56	172

Special Metals Inconel Alloy 617

Inconel Alloy 617 Qhov Zoo

Inconel 617 tuav ntau qhov zoo dua li tus qauv Nickel. Inconel 617 yog ib qho muaj zog alloy paub txog nws qhov kub thiab txias zog thiab oxidation tsis kam. Cov hlau no tau yooj yim tsim thiab welded los ntawm cov txheej txheem ib txwm ua, thiab tuaj yeem tsim tau yooj yim los ua cov haujlwm tseem ceeb. Inconel 617 tuaj yeem tsim kub txog 2200º F, thiab txias tsim ntawm 1900º F. Cov muaj pes tsawg leeg ntawm Inconel 617 ua rau nws resistant rau ob qho tib si txo thiab oxidizing xov xwm. Qhov siab zog-rau-qhov hnyav piv ntawm cov hlau no ua rau nws zoo tagnrho rau feem ntau cov ntawv thov kev lag luam.
