UNS N06022
Raws li tus neeg muag khoom thiab chaw tsim khoom nyob rau hauv Suav teb, GNEE Steel muab tus nqi -nickel zoo- raws li cov khoom siv alloy.
- Xa E-mail:ss@gneesteel.com
- Tel:+8615824687445
UNS N06022, tseem hu ua alloy C22, yog ntau yam austenitic nickel-chromium-molybdenum-tungsten alloy nrog txhim khu kev tiv thaiv rau pitting, crevice corrosion thiab kev nyuaj siab corrosion cracking. Cov ntsiab lus chromium siab muab kev tiv thaiv zoo rau oxidizing media thaum molybdenum thiab tungsten cov ntsiab lus muab kev tiv thaiv zoo los txo cov xov xwm. Cov nickel hlau alloy no kuj muaj kev tiv thaiv zoo rau oxidizing aqueous xov xwm nrog rau cov chlorine ntub dej thiab cov khoom sib xyaw uas muaj nitric acid lossis oxidizing acids nrog chlorine ions.
Tshuaj muaj pes tsawg leeg
Cov tshuaj muaj pes tsawg leeg ntawm UNS N06022 tau piav qhia hauv cov lus hauv qab no.
| Element | Cov ntsiab lus (%) |
|---|---|
| Nickel. Ni | 50.01 - 63 |
| Chromium, Cr | 20 - 22.5 |
| Molybdenum, Mo | 12.5 - 14.5 |
| Hlau, Fe | 2-6 |
| Tungsten, W | 2.5 - 3.5 |
| Cobalt, Co | Tsawg dua lossis sib npaug li 2.5 |
| Manganese, Mn | Tsawg dua lossis sib npaug rau 0.50 |
| Vanadium, V | Tsawg dua lossis sib npaug rau 0.35 |
| Silicon, Sib | Tsawg dua lossis sib npaug rau 0.080 |
| Phosphorus, P | Tsawg dua lossis sib npaug rau 0.020 |
| Sulfur, S | Tsawg dua lossis sib npaug rau 0.020 |
| Carbon, C | Tsawg dua lossis sib npaug rau 0.015 |
Lub cev muaj zog
Lub cev lub cev ntawm UNS N06022 yog tabulated hauv qab no.
| Cov khoom | Metric | Imperial |
|---|---|---|
| Qhov ntom | 8.61 g / cm²3 | 0.311 lb/in3 |
| Melting point | 1351 - 1387 degree | 2464 - 2529 degree F |
Mechanical Properties
Cov lus hauv qab no qhia cov khoom siv kho tshuab ntawm UNS N06022.
| Cov khoom | Metric | Imperial |
|---|---|---|
| Tensile zog | 772mpa ua | 11 2000 psi |
| Yield zog | 365 MPa rau | 5 2900 psi |
| Elongation thaum so | 54% | 54% |
| Elastic modulus | 209 GPA | 30 300 TZS |
| Hardness, Rockwell B | 89 | 89 |
Cov yam ntxwv ntawm Hastelloy UNS N06022
- Resistant rau pitting, crevice corrosion thiab kev nyuaj siab corrosion cracking
- Kev ua haujlwm zoo rau ob qho tib si txo thiab oxidizing xov xwm
- Zoo heev tiv thaiv oxidizing aqueous media
- Exceptional tsis kam mus rau ntau yam ntawm cov txheej txheem tshuaj ib puag ncig xws li muaj zog oxidizers xws li ferric acids, acetic anhydride, thiab seawater thiab brine daws.
- Resistant tsim ntawm grain- ciam teb precipitates nyob rau hauv lub weld tshav kub-cuam tshuam cheeb tsam
- Weldability zoo heev
Pob & Xa
