4130 alloy txias dov steel yeeb nkab
Qeb: 4130
Txheem: Astm A519
Hom: Seamless
Ntev: 5.8m, 6m thiab yuav tsum tau ntev
Raws li tus neeg muag khoom thiab chaw tsim khoom nyob rau hauv Suav teb, GNEE Steel muab tus nqi -nickel zoo- raws li cov khoom siv alloy.
- Xa E-mail:ss@gneesteel.com
- Tel:+8615824687445
GNEE 4130 Kov Rolled Steel Yeeb Nkab Qhia
4130 alloy txias dov yeeb nkab
4130 Txias Chromoly Steel Tube yog lub chromium-molybdenum cov raj txias uas yog tau zoo dua los ntawm kev ua kom txias dua tshiab, thiab ua kom zoo dua qub {{90.15-0.25%) Raws li cov raj khoom. Cov khaub ncaws ua kom sov li qub Sab hauv qab qhov sib luag ro tsawg dua lossis sib npaug rau 0.4μm, uas tau ua tiav cov cai uas muaj high-precision high-precision high high-precision high hydraulic thiab pneumatic cov tshuab.
Nyob rau hauv cov nqe lus ntawm cov neeg kho tshuab, tom qab tsim nyog quenching thiab tempering, thiab lub zog} mpa}}}}}}}}}}}}} {2} {{} {. kev ua haujlwm Hardening cov nyhuv coj los ntawm kev ua haujlwm txias tuaj yeem ua rau cov khoom siv tawv uas yuav tsum tau hnav tsis zoo thiab ua rau muaj kev ntxhov siab ntau dua rau kev hloov pauv ntawm cov khoom lag luam uas tsis muaj zog yog li, thiab cov khoom siv tsis muaj zog. tias ntawm kub-rolled tub .
4130 cov raj kheej txias yog dav siv rau hauv cov kab mob voos kheej kheej, kev sib tw nrog cov kev ua kom zoo nkauj thiab lwm tus mm} Kuv tuaj yeem muab ntau yam kev kho cua sov xws li annealing, noraling lossis quenching thiab ua kom zoo nkauj yog kev tswj hwm kom tshem tawm cov leeg txias, 4130 lub raj txias uas tau dhau los ua cov khoom tseem ceeb hauv Lub teb ntawm precision machinery manufacturing .
GNEE 4130 Kaws Cov Nplaim Yeeb Nkab Daim Ntawv Tshwj Xeeb
4130 Txias-Rolled Alloy Steel Tube Kev Qhia Tshwj Xeeb
| Cov cuab yeej qeb | Kev Ntsuas Cov Qauv / Cov Lus Qhia |
|---|---|
| Qho loj | Od:5-200 hli (Precision Txias-Rolled) Phab Ntsa Thickness:0.5-10 hli Ntev:1-8 m (txuj ci), customizable txog 12 m |
| Tus qauv | - ASTM A519(Precision seamlessatical tubing) - DIN 2391(High-Precision Txias-Rolled Tubes) - GB / T 3639(Suav teb chaws) - Ams 6371(Aerospace-qib) |
| Nto Kho | - Kom zoo sib tsoo / polishing(Ra tsawg dua los yog sib npaug rau 0.4 μm) - Phosphaited / Black Oxide(tiv thaiv xeb + lubrication) - Tawv chrome plating(Hnav tsis kam, rau cov thooj voos kheej kheej) - Passivation(txhim kho corrosion resistance) |
| Kev nyuaj | - Annealed:170-220 HB - Raws li-dov (tsis kho):250-320 HB - Quenched & tempered (q & t):30-35 HRC |
| Ceev | 7.85 g / cm³ (tib yam li kub-rolled) |
| Cov Khoom Siv Cov Khoom Siv | Cov Kev Siv Chemistry (ASTM A519): - C: 0.28–0.33% - CR: 0.80-1.10% - MO: 0.15-0.25% - MN: 0.40-0.60% - Si: 0.15-0.35% - P / S: Tsawg dua lossis sib npaug rau 0.025% (cov impurity tsis loj) |
| Cov Khoom Siv Neeg Kho Tshuab | Q & T Mob Mob (Raug): - Tensile lub zog: 700-850 MPa - Putt lub zog: 500-650 mpa - elongation: 12-15% - Qeeb Qeeb Qeeb: ≈45% ntawm lub zog tensile |
| Thawj cov ntawv thov | Cov Tshuab Hydraulic:Lub tog raj kheej qhob, Servo Valve lub cev Cov Khoom Siv High-agent:Aircraft Actuatators, Sib tw Drive Shafts Muaj Machinery:Daim Ntawv Qhia Txog Precision Cov Rods, Cov Khoom Siv Bellows Khoom Zog Khoom:Metered Twj Tub Khaub Tais, Cov Tsev Nruab Nrab Kev Ntsuas Siab |
4130 Yeeb Nkab Yeeb Nkab Cov Tshuaj Sib Tw
| Lub ntsiab | Cov ntsiab lus (%) |
|---|---|
| Hlau, FE | 97.03 – 98.22 |
| Chromium, cr | 0.80 – 1.10 |
| Manganese, mn | 0.40 – 0.60 |
| Carbon, c | 0.280 – 0.330 |
| Silicon, si | 0.15 – 0.30 |
| Molybdenum, mo | 0.15 – 0.25 |
| Sulphur, s | 0.040 |
| Phosphorous, p | 0.035 |
GNEE 4130 Alloy Steel Yeeb Nkab Sij Hawm
4130 Txias-Rolled Tube Cov Qauv Loj
| Od (hli) | Cov Phab Ntsa Thickness (hli) | Cov Kev Siv Raug Raug |
|---|---|---|
| 5–20 | 0.5, 0.8, 1.0, 1.5 | Cov lus qhia kev ua hauj lwm zoo, cov khoom siv kho mob |
| 20–50 | 1.0, 1.5, 2.0, 2.5, 3.0 | Hydraulic Thooj Voos Kheej Kheej, Tshuab Pneumatic, Sib tw Drive Shafts |
| 50–100 | 2.0, 2.5, 3.0, 4.0, 5.0 | Lub dav hlau Actuast, siv cov kev txuas rau cov khoom siv (cov kab muaj roj siab |
| 100–200 | 3.0, 4.0, 5.0, 6.0, 8.0 | Lub tsev zog khoom siv, qhov system hydraulic hluav taws xob |
Gnee Pab Pawg Hoobkas Ib puag ncig
Gnee Group 4130 Cov Yeeb Nkab Hlau Chaw Hoobkas
Gnee Group 4130 Alloy Yeeb Ntim
Gnee Pab Pawg 4130 Ntim Ntim
Gnee Pab Pawg Kev Ntsuas
Gnee Group Alloy 4130 Khaub Ncaws Rolled Steel Yeeb Tsua
Cov FAQ
1. Dab tsi yog AISI 4130?
AISI 4130 yog lub chromoly steel, tseem hu ua chrome Moly steel {} Nws yog qhov sib npaug, kev sib npaug, thiab tshuab {4 4}}
2. Puas muaj cov hlau chrome-molybdenum hlau zoo dua li cov hlau?
Dab tsi paub qhov txawv Chrome-Molybdenum hlau los ntawm lwm hom steel yog nws lub zog tshaj plaws tsis muaj kev sib tw lossis dej noo .
{{0 {}}} yuav 4130 chrome-molybdenum steel hlau xeb?
Ob qho tib si 4140 thiab 4130 tus hlau yog cov hlau loj uas muaj lub zog zoo, kev ua tsis tau zoo, thiab corrosion tsis kam {}}
{{04. yog 4130 ib cov roj carbon hlau?
4130 Cov hlau roj hmab yog cov siv roj carbon tsawg nrog kwv yees li ntawm cov steel thiab moly beld thiab moly beld thiab tuaj yeem kho cua sov yooj yim dua li lwm cov hlau me me.
Cim npe nrov: 4130 Alloy Txias Rolled Steel Yeeb Nkab, Tuam Tshoj 4130 Alloy Txias Rolled Steel Yeeb Nkab Cov Hlau Yeeb Nkab
