UNS N02201
UNS N02201 yog ib qho kev lag luam ntshiab wrought npib tsib xee nrog cov khoom siv kho tshuab zoo thiab ua haujlwm zoo rau ntau tus neeg ua haujlwm corrosive. Nickel 201 muaj cov ntsiab lus carbon tsawg (txog 0.02%) thiab tsim nyog rau cov ntawv thov saum toj no 315 degree, feem ntau hauv cov khoom siv ua zaub mov, tshuaj thauj cov nruas, cov khoom siv alkali tuav thiab kav dej, cov khoom siv hluav taws xob, aerospace thiab missile Cheebtsam, foob pob hluav taws lub cev, cov khoom siv magnetostrictive.
Xa kev nug
Tsham tam sim no
Raws li tus neeg muag khoom thiab chaw tsim khoom nyob rau hauv Suav teb, GNEE Steel muab tus nqi -nickel zoo- raws li cov khoom siv alloy.
- Xa E-mail:ss@gneesteel.com
- Tel:+8615824687445
Khoom Taw qhia
UNS N02201 yog ib qho kev lag luam uas yog npib tsib xee uas muaj cov pa roj carbon ntau tshaj 0.02%. Cov hlau no muaj cov khoom siv hluav taws xob zoo heev tshaj qhov kub ntau yam. Nws yog corrosion resistant nyob rau hauv nruab nrab mus rau nruab nrab txo ib puag ncig. UNS N02201 yog ferromagnetic. Nws muaj ntau dua thermal thiab hluav taws xob conductivity tshaj nickel-based alloys, stainless hlau, thiab cov hlau tsis tshua muaj hlau.
Tshuaj muaj pes tsawg leeg
| Element | Cov ntsiab lus (%) |
|---|---|
| Nickel, Nia | Ntau dua lossis sib npaug li 99 |
| Hlau, Fe | Tsawg dua lossis sib npaug rau 0.4 |
| Manganese, Mn | Tsawg dua lossis sib npaug rau 0.35 |
| Silicon, Sib | Tsawg dua lossis sib npaug rau 0.35 |
| tooj, Cu | Tsawg dua lossis sib npaug rau 0.25 |
| Carbon, C | Tsawg dua lossis sib npaug rau 0.020 |
| Sulfur, S | Tsawg dua lossis sib npaug rau 0.010 |
Lub cev muaj zog
| Cov khoom | Metric | Imperial |
|---|---|---|
| Qhov ntom | 8.89 g / cm33 | 0.321 lb/in3 |
| Melting point | 1435 - 1446 degree | 2615 - 2635 degree F |
Thermal Properties
| Cov khoom | Metric | Imperial |
|---|---|---|
| Thermal expansion co-efficient (@20-100 degree /68-212 degree F) | 13.1 µm / m degree | 7.28 µin / hauv degree F |
| Thermal conductivity | PEB 79.3 W/mK | 550 BTU.in/hrft². degree F |
Cov khoom ntawm UNS N02201
- Zoo corrosion kuj mus rau acids thiab bases, feem ntau pab tau nyob rau hauv txo tej yam kev mob.
- Zoo heev corrosion kuj rau alkaline puag, mus rau lub xeev molten.
- Nyob rau hauv acidic, alkaline thiab nruab nrab ntsev tov, cov khoom qhia zoo corrosion kuj, tab sis loj corrosion tshwm sim nyob rau hauv oxidizing ntsev tov.
- Resistant rau tag nrho cov roj qhuav ntawm chav tsev kub, tuaj yeem siv tau txog 550C hauv cov tshuaj chlorine qhuav thiab hydrogen chloride.
- Kev tiv thaiv rau cov ntxhia acids txawv nrog qhov kub thiab txias thiab seb cov tshuaj puas yog aerated. Zoo corrosion kuj nyob rau hauv degassed acids.
- Yuav luag tsis cuam tshuam los ntawm intergranular corrosion saum 315C, chlorates yuav tsum tau khaws cia kom tsawg.
Daim ntawv thov ntawm Nickel UNS N02201 Alloy
- Chemical tanks
- Pulp & Ntawv Industries
- Petrochemical Kev Lag Luam
- Fais Fab Tsim Kev Lag Luam
- Roj & Roj Industries
- Desalination
- Architecture thiab kev tsim kho
- Khoom noj khoom haus
- Biofuels cog
- Cargo tanks rau nkoj thiab tsheb thauj khoom
- Chemical Industries Pumps, kiv cua, centrifuges, sulfur melting coils
- Digester hauv sulphate thiab sulfite nroj tsuag, tshuab tso tsheb hlau luam, tshuab kab
Ntim & Shipping
7
Cim npe nrov: uns n02201, Tuam Tshoj uns n02201 lwm tus neeg
