Nickel alloy X750 /Inconel X750yog cov nag lossis daus-tawv tawv nickel-chromium alloy siv rau nws cov corrosion thiab oxidation tsis kam thiab siab zog ntawm qhov kub thiab txias mus rau 1300 degree F. Txawm hais tias feem ntau ntawm cov nyhuv los nag lossis daus hardening poob nrog qhov kub siab tshaj 1300 degree F, cov khoom siv kho cua sov muaj txiaj ntsig zoo. lub zog mus txog 1800 degree F. Alloy X-750 kuj muaj cov khoom zoo heev mus rau qhov kub thiab txias.
Tshuaj muaj pes tsawg leeg
Cov tshuaj muaj pes tsawg leeg ntawm Inconel® X750 yog qhia hauv cov lus hauv qab no:
| Element | Tsawg% | Max % |
|---|---|---|
| C | – | 0.08 |
| Mn | – | 1.00 |
| Si | – | 0.50 |
| S | – | 0.01 |
| Cr | 14.00 | 17.00 |
| Ni | 70.00 | – |
| Nb/Cb | 0.70 | 1.20 |
| Ti | 2.25 | 2.75 |
| Al | 0.40 | 1.00 |
| Fe | 5.00 | 9.00 |
| Co | – | 1.00 |
| Ta | – | 0.05 |
| Cu | – | 0.50 |
Mechanical & Physical Properties
| Mechanical & Physical Properties | 20 degree | 200 degree | 400 degree | 427 degree | 538 degree | 600 degree | 649 degree | 732 degree | 816 degree |
|---|---|---|---|---|---|---|---|---|---|
| Qhov kawg Tensile Strength / MPa | 1503.1 | 1351.4 | 744.6 | 688.8 | - | 622.6 | 593 | - | 600 |
| 0.2% Yield Strength /MPa | 979.1 | 737.7 | 365.4 | 340.6 | - | 278.5 | 250.3 | - | 253.7 |
| Elongation% | 36 | 49 | 47 | 47 | - | 46 | 47 | - | 48 |
| Charpy Impact V-notch / J | 436.6 | 115.2 | 189.8 | - | - | - | - | - | - |
| Coefficient ntawm Thermal Expansion µm / m⁰C | - | - | - | 14.22 | 14.94 | 15.12 | 15.48 | 15.66 | 15.84 |
| Thermal conductivity / kcal / (hr.m. degree) | - | - | 10 | 11.2 | 12.1 | 12.9 | 15 | 15.66 | 15.84 |
| Modulus ntawm Elasticity / x105MPa | - | - | 1.95 | 1.89 | - | 1.8 |
Nickel X750 Alloy Cov txiaj ntsig suav nrog:
- Lub zog siab ntawm qhov kub txog 1500 degree F (816 degree) tom qab kev kho cua sov tsim nyog
- Creep-rupture lub zog ntawm qhov kub thiab txias txog li 700oC (1290oF)
- High tensile thiab creep-rupture zog
- Tsis kam mus rau ntau yam kev lag luam corrosives nyob rau hauv ob qho tib si oxidizing thiab txo cov mob
- Ua haujlwm tau zoo nrog rau machinability thiab vuam
- Kev tiv thaiv rau chloride ion kev nyuaj siab-corrosion tawg
- Dej nag hardenable
Inconel X-750 Yam ntxwv:
- Hlau-Nickel-Chromium raws li alloy hardened los ntawm nag lossis daus ntawm cov khoom Aluminium thiab Titanium.
- Zoo corrosion kuj thiab oxidation kuj txawm nyob rau ntawm qhov kub thiab txias rau 980C,
- Zoo mechanical zog mus txog 800 degree,
- Zoo so tsis kam mus txog 540 degree,
- Zoo processability thiab weldability,
- Mechanical zog zoo heev nyob rau hauv qhov kub thiab txias ib puag ncig.
