Inconel Alloy 718 Cov Yeeb Nkab Fittingskev piav txog
Gnee Inconel Alloy 718 Cov Yeeb Nkab Fittings
Inconel 718 Alloy cov yeeb nkab fittings yog muaj npe rau lawv lub zog siab, ua kev ua tau zoo tshaj plaws, ua rau lawv xav tau ib puag ncig muaj xws li aerospace thiab lub hwj chim siab. Qhov tseem ceeb yam suav nrog tus nqi siab thiab nyuaj machining vim yog lub alloy lub siab hardness. Koj tuaj yeem nrhiav cov fittings xws li luj tshib, Tees, thiab Couplings nyob rau ntau yam qauv thiab qhov ntau thiab tsawg mus ntsib cov khoom siv hluav taws xob ntau yam.
Inconel 718 Cov fittings tau siv los txuas lossis reroute cov raj xa dej xa mus rau kev ntsuas siab heev. Cov neeg kho tshuab thiab cua sov cov yam ntxwv ntawm cov fittings kom sib raws cov qauv kev lag luam. Cov fittings no yog tsim los ntawm nickel {{3} based alloy feem ntau muaj ntawm npib tsib xee, chromium, thiab hlau. Niobium thiab molybdenum tau ntxiv rau lub zog. Inconel 718 yog qhov tshwj xeeb nyob rau hauv uas nws muaj zog heev, xeb {{{}} tsis kam, thiab tiv taus nkag thiab galling. Tag nrho cov khoom ntawm cov khoom no excel nyob rau ib puag ncig raug rau huab ua kom zoo thiab kub.
Cov fittings, conforming rau ASTM B366 Txuj Ci rau Inconel 718 fittings, tau siv dav hauv ib lub zog, thiab hluav taws xob kev ntseeg siab thiab qhov kub thiab txias yog qhov tseem ceeb. Thaum Inconel 600 thiab Inconel 601 fittings yog zoo dua rau lwm cov fittings nyob rau hauv cov nqe lus ntawm oxidation thiab carburization tiv thaiv lub neej thiab siab} kub ruaj khov. Inconel 625 tseem paub tias yog xeb - tsis kam.
Inconel Alloy 718 Cov Yeeb Nkab Fittings Cov Lus Qhia
TSHWJ XEEB NTAWM INCOREL 718 FITTINGS
| Hom | Cov Lus Qhia Tshwj Xeeb |
|---|---|
| Tus qauv | ASTM B366 / ASME SB366, ASTM B564 / ASME SB564 |
| Qho loj | ASME / Ansi B16.9, ASME B16.28, BSIO, ASMAS, ASCE 16.11, BSECUE 16.11, BSE10, YOG 631 NPE, API, DIN, JIS, MSS SP 44 |
| Fittings Thickness | SCH10, SCH30, SCH30, SCH60, XS, Sch80, SCH140, SCH160, XXS (muaj nrog NACE MR 01-75) |
| Fittings Loj | Seamless tw wandd fittings: 1/2 "- 10" Welded Pob Ntshoo Weld Fittings: 1/2 "- 48" StackardWeld & Screwed - threaded: 1/8 "NB rau 4" NB |
| Dabtsi yog khoov Radius | R=ID, 2D, 3D, 5D, 6D, 8D, 10D lossis kev cai |
| Siab Ntsuam | Threaded Kawg: 2000 Lb / 3000 LB / 6000 LB Qhov rooj - weld kawg: 3000 lb / 6000 Lb / 9000 LB |
| Xov Hom | NPT, BSPT, BSPP |
| Haum hom | Seamless / welded / ntshisdedd / threaded / fab |
| Cov txheej txheem tsim khoom | Thawb, nias, ntaus, nrum, thiab lwm yam. |
Inconel Alloy 718 Cov Yeeb Nkab Fittings Cov Lus Qhia
Tshuaj lom neeg muaj pes tsawg leeg 718 cov yeeb nkab fittings
| Teem nqi | C | Mn | Si | S | P | Zaum fe | Ni | Cr | Mo | Nb + ta | Al | Ti |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inconel 718 | Tsawg dua los yog sib npaug rau 0.08 | Tsawg dua los yog sib npaug rau 0.35 | Tsawg dua los yog sib npaug rau 0.35 | Tsawg dua los yog sib npaug rau 0.015 | Tsawg dua los yog sib npaug rau 0.015 | Seem | 50–55 | 17–21 | 2.8–3.3 | 4.75–5.5 | 0.2–0.8 | 0.65–1.15 |
Cov cuab yeej kho tshuab ntawm inconel 718 fittings
| Ntiag tug | Inconel 718 Tus Nqi |
|---|---|
| Ceev | 8.19 g / cm³ |
| Melting point | 1260-1336 Qib |
| Lub zog tensile | Ntau dua los yog sib npaug rau 1375 mpa (200 KSI) |
| Tos lub zog (0.2%) | Ntau dua los yog sib npaug rau 1100 mpa (160 ksi) |
| Elongation | Ntau dua los yog sib npaug rau 12% |
| Kev nyuaj | Rockwell C 35-45 |
Ntau hom ntawm inconel alloy 718 cov yeeb nkab fittings
Incmel 718 Cov Yeeb Nkab Fittings
Luj tshib (90 degree, 45 degree, ntev voj, luv vojvoog)
Tsim los hloov cov kev coj ua, cov tais tais no muaj nyob rau ntau yam hluav taws xob, muab cov qauv hloov kho thaum tswj cov txheej txheem muaj zog thiab corrosion tsis kam.
Tees (sib npaug Tees, txo cov nqi)
Peb lub Tees yog qhov zoo tshaj plaws rau faib lossis sib txuas nrog cov tshuab luam yeeb. Lawv tau ruaj khov nyob rau hauv thermal kev ntxhov siab thiab muaj nyob rau hauv ob qho kev sib npaug thiab txo cov diameters kom haum rau ntau yam ntawm cov yeeb nkab tsim.
Reducers (concentric, eccentric)
Cov fittings pab kev hloov ntawm cov yeeb nkab ntau yam tsis muaj kev cuam tshuam kua dej ntws. Renucers mloog zoo rau cov yeeb nkab kho kom haum, thaum eccentric rollucers pab tiv thaiv cov cua ntxiv hauv kab rov tav.
Pob qij txha (tag nrho, ib nrab)
Peb cov fittings tag nrho thiab ib nrab fittings sib txuas nrog ob qho yeeb nkab ntu thiab tau tsim kho kom muab cov kev sib khi zoo dua, weldability tuav lub peev xwm hauv kev siv cov ntawv thov.
Stub kawg (luv luv / ntev)
Tus txiv neej xaus yog feem ntau siv rau kev siv ceg tawv thiab muaj nyob rau hauv luv luv thiab ntev versions thiab ntev version, yooj yim disassembly thiab txij nkawm.
Koomhaum, hla, thiab cov stitings
Cov khoom sib xyaw me me no ua lub luag haujlwm tseem ceeb hauv kev hloov pauv, ceg, thiab kev nyab xeeb yeeb nkab khiav thaum tswj cov xau- ntawv ua yeeb yam.
Cov Fittings Kev Cai
Gnee Steel kuj tseem muaj cov customized inconel 718 fittings kom tau raws li koj cov kev xav tau. Seb nws puas yog tsis- qauv geometry, peb muab cov kev daws teeb meem xaus, peb muab cov ntaub ntawv tshwj xeeb rau cov ntaub ntawv thiab cov khoom siv traceability.
Siab {{0 {}} cov kev ntsuas kub rau Alloy 718 Seamless Reducer Fittings (PSIG)
| Qho so | Siab chav 150 | Siab Chav 300 | |||||
|---|---|---|---|---|---|---|---|
| Degree F | tiv kis | ¼ - 1 nti | 1¼ - 2 nti | 2½ - 3 nti | ¼ - 1 nti | 1¼ - 2 nti | 2½ - 3 nti |
| -20 rau 150 | -29 txog 66 | 300 | 2000 | 1500 | 1000 | (Nco tseg: Chav kawm 300 tawm kev ntsuas tshwm sim los ntawm 1¼ ntiv tes hauv cov ntaub ntawv no) | |
| 200 | 93 | 265 | 1785 | 1350 | 910 | ||
| 250 | 121 | 225 | 1575 | 1200 | 825 | ||
| 300 | 149 | 185 | 1360 | 1050 | 735 | ||
| 350 | 177 | 150 | 1150 | 900 | 650 | ||
| 400 | 204 | – | 935 | 750 | 560 | ||
| 450 | 232 | – | 725 | 600 | 475 | ||
| 500 | 260 | – | 510 | 450 | 385 | ||
| 550 | 288 | – | 300 | 300 | 300 |
Dag Daim Ntawv Teev Tseg ntawm DIN 2.4668 YEEB NKAUJ Kawg Cap
| Nominal yeeb nkab loj (nps) | Sab nraud ntawm lub taub nyob bevel (nti) | Sab hauv txoj kab uas hla (ntiv tes) | Phab Ntsa Thickness | Center - rau -}}} qhov ntev kawg a, b, c (ntiv taw) | Zuag qhia tag nrho ntev h (ntiv tes) | OVERALL NTES F (INCHES) |
|---|---|---|---|---|---|---|
| ½ rau 2½ | +0.06 / -0.03 | Tsis teev | Tsis pub tsawg tshaj 87.5% ntawm nominal tuab | ± 0.06 | ± 0.06 | ± 0.12 |
| 3 txog 3½ | ± 0.06 | ± 0.06 | Tsis pub tsawg tshaj 87.5% ntawm nominal tuab | ± 0.06 | ± 0.06 | ± 0.12 |
| 4 | ± 0.06 | ± 0.06 | Tsis pub tsawg tshaj 87.5% ntawm nominal tuab | ± 0.06 | ± 0.06 | ± 0.12 |
| 5 txog 8 | ± 0.06 | ± 0.06 | Tsis pub tsawg tshaj 87.5% ntawm nominal tuab | ± 0.06 | ± 0.06 | ± 0.25 |
| 10 txog 18 | +0.16 / -0.12 | ± 0.12 | Tsis pub tsawg tshaj 87.5% ntawm nominal tuab | ± 0.09 | ± 0.09 | ± 0.25 |
| 20 txog 24 | +0.25 / -0.19 | ± 0.19 | Tsis pub tsawg tshaj 87.5% ntawm nominal tuab | ± 0.09 | ± 0.09 | ± 0.25 |
| 26 txog 30 | +0.25 / -0.19 | ± 0.19 | Tsis pub tsawg tshaj 87.5% ntawm nominal tuab | ± 0.12 | ± 0.19 | ± 0.38 |
| 32 txog 48 | +0.25 / -0.19 | ± 0.19 | Tsis pub tsawg tshaj 87.5% ntawm nominal tuab | ± 0.19 | ± 0.19 | ± 0.38 |
Hais Txog Gnee Steel
GNee steel tshwj xeeb hauv kev tsim khoom thiab muag ntawm ntau qhov nickel {}}}}}}}}}}}}}}}}}} 800H / HT, Incoloy 825, Monel Alloy 400, Monel K500, thiab High-kub alloys. Gnee Steel cov khoom yog dav siv nyob rau hauv Aerospace, tshuaj lom neeg, hluav taws xob hluav taws xob, siv hluav taws xob, thiab lub zog hluav taws xob, thiab lub zog nuclear zog, thiab lub zog nuclear lub zog. Peb tseem muab cov kev cai ua kom haum rau cov neeg siv khoom xav tau. Rau alloy tus nqi nug cov lus nug lossis customized alloy cov kev daws teeb meem, thov hu rau peb rau ib nqe lusss@gneesteel.com.
