Super Nickel Alloy N06601 / 6023 Inconel 601 daim ntawv / phaj npib tsib xee
Raws li tus neeg muag khoom thiab chaw tsim khoom nyob rau hauv Suav teb, GNEE Steel muab tus nqi -nickel zoo- raws li cov khoom siv alloy.
- Xa E-mail:ss@gneesteel.com
- Tel:+8615824687445
Npe: Nickel alloy N06601 / 6023 Inconel 601 sheet / phaj
Puab |
Kev qhia tshwj xeeb |
Daim Ntawv Foos |
Lwm tus |
Daim ntaub |
Thickness: {0.40-4.75 hli, Dav Dav: 1000,1219,1500mm |
Tag nrho chil lossis daim ntawm nws |
Txias annealed, nto 2B, 2e |
Lub tais |
Thickness: 4.76-60 mm, dav: 1500,2000,2500mm, ntev: 3000 _6000,8500mm (hauv qab 10mm Phaj tuaj yeem tau coiled) |
Tag nrho chil lossis daim ntawm nws |
Ib Leeg Kub Rolling, Khoom Siv Annealed State, Nto 1D |
Txoj siv |
Thickness: {0.10-3.0 hli, dav: {{1 hli} hli |
Tag nrho chil lossis teev loj |
Txias annealed, nto 2B, 2e |
Bar & pas nrig |
Rolled bek 5-45 hli, ntev tsawg dua lossis sib npaug rau 1500mm |
Polished bar (voj voog, xwmfab) |
Daws annealing, descaling |
Forged barø 26-245 hli, ntev tsawg dua lossis sib npaug rau 4000mm |
Tshuaj Muaj Tshuaj
Cov tshuaj lom neeg muaj kuab lom ntawm NICROFER 6023 alloy tau teev nyob rau hauv cov lus hauv qab no.
Lub ntsiab |
Cov ntsiab lus (%) |
| Npib tsib xee, ni | 58-63 |
| Chromium, cr | 21-25 |
| Aluminium, al | 1-1.7 |
| Tooj liab, cu | 1 |
| Manganese, mn | 1 |
| Silicon, si | 0.5 |
| Carbon, c | 0.1 |
| Sulphur, s | 0.015 |
| Hlau, FE | Seem |
Cov Khoom Siv Lub Cev
Cov lus hauv qab no qhia txog cov yam ntxwv ntawm lub cev ntawm NICROFER 6023 alloy .
Cov Khoom Siv |
Me me | Muaj huab tais |
| Ceev | 8.11 g / cm3 | 0.293 lb / hauv3 |
| Melting taw tes | 1360-1411 degree | 2480-2572℃f |
Cov Khoom Siv Neeg Kho Tshuab
Cov cuab yeej ua haujlwm ntawm NICROFER 6023 alloy tau tso tawm hauv cov lus hauv qab no.
Cov Khoom Siv |
Me me | Muaj huab tais |
| Tensile lub zog (kev daws annealed) | 760 MPa | 110000 PSI |
| Yield lub zog (daws annealed) | 450 MPa | 65300 PSI |
| Elongation thaum so (tov annealed) | 42% | 42% |
Thermal Khoom
Cov khoom cua sov ntawm NICROFER 6023 alloy tau muab nyob rau hauv cov lus hauv qab no.
Cov Khoom Siv |
Me me | Muaj huab tais |
| Thermal nthuav kev nthuav dav (@ 20-100℃/ 68-212℃f) | 13.75 μm / m degree | 7.639 μin / hauv Degree F |
| Thermal conductivity | 11.2 W / MK | 77 {{. 7 btu . hauv / hrft². Degree F |
