Monel K500 yeeb nkab fittings

Monel K500 Yeeb Nkab Fittings yog tsim los ntawm nickel-tooj liab alloy nrog zoo corrosion kuj thiab siab zog. Cov yeeb nkab fittings no feem ntau siv rau hauv marine, industrial & chemical processing applications vim lawv muaj peev xwm tiv taus dej ntsev, sulfuric acid, hydrochloric acid, alkalis & lwm yam tshuaj corrosive.

Xa kev nug

Tsham tam sim no

Raws li tus neeg muag khoom thiab chaw tsim khoom nyob rau hauv Suav teb, GNEE Steel muab tus nqi -nickel zoo- raws li cov khoom siv alloy.

Xa E-mail:ss@gneesteel.com
Tel:+8615824687445

Khoom Taw qhia

Monel K500Cov yeeb nkab fittings muab kev tiv thaiv zoo heev rau pitting, kev nyuaj siab-corrosion tawg, yaig-corrosion, thiab erosive hnav. Cov fittings no zoo heev ductility thiab toughness. Monel K500 Yeeb Nkab Fittings tuaj nyob rau hauv ntau yam duab, qhov ntau thiab tsawg, thiab cov qauv. Lawv suav nrog threaded fittings xws li 90 degree luj tshib, 45 degree luj tshib, tees, crosses, couplings, kawg hau, thiab plugs. Kuj tseem muaj pob tw weld fittings xws li luv luv-radius luj tshib, lub luj tshib ntev, concentric reducers, eccentric reducers, thiab kaus mom. Muaj cov socket-welded fittings xws li txo tee's, socket-welded luj tshib, socket welded cross' thiab lwm yam, muaj nyob rau hauv cov khoom no qib.

ALLOY K500 PIPE FITTING EQUIVALENT QIB

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
Monel K500	2.4375	N05500	-	-	-	-	-

MONEL K500 Pipes FITTING CHEMICAL COMPOSITION

Qib	C	Mn	Si	Cu	S	Ti	Ni	Al	Fe
Monel K500	0.25 max	1.5 max	0.5 max	27.0 – 33.0	0.010 max	0.35 – 0.85	63.0 feeb	2.3 – 3.15	0.5 – 2

Alloy K500 Pipes FITTING MECHANICAL PROPERTIES

Element	Qhov ntom	Melting Point	Tensile zog	Yield zog (0.2% Offset)	Elongation
Monel K500	8.44g 3	1350 degree (2460 degree F)	Psi - 160000, MPa - 1100	Psi - 115000, MPa - 790	20 %

monel material pipe fitting

Qhov sib txawv ntawm Monel K500 Fittings thiab 400

Monel K500 thiabMonel 400yog cov nickel-tooj liab alloys uas muaj kev tiv thaiv corrosion zoo heev hauv ntau qhov chaw. Qhov sib txawv tseem ceeb ntawm ob yog qhov sib ntxiv ntawm txhuas thiab titanium rau Monel K500, uas ua rau nws muaj zog thiab tawv. Monel K500 yog qhov tsim nyog rau cov ntawv thov kev ntxhov siab xws li twj tso kua mis thiab cov khoom siv valve thiab marine propellers shafts. Monel 400 tseem siv dav hauv ntau qhov kev lag luam, tab sis nws feem ntau tsim nyog rau cov ntawv thov tsawg dua qhov nws zoo heev corrosion kuj yog qhov tseem ceeb.
