Inconel 690 Alloy Round Pipes
Ntev: Customized los ntawm cov neeg siv khoom thiab feem ntau 6000mm
Steel Qib: Nickel Alloy Yeeb Nkab
Khoom siv: Inconel 690
Thauj Pob: Sea-Worthy Packing
Specification: OD 12.7 ~ 273mm; WT 1.24 ~ 15.09 hli
Raws li tus neeg muag khoom thiab chaw tsim khoom nyob rau hauv Suav teb, GNEE Steel muab tus nqi -nickel zoo- raws li cov khoom siv alloy.
- Xa E-mail:ss@gneesteel.com
- Tel:+8615824687445
Inconel 690 alloy yeeb nkab yog ib qho alloy feem ntau yog siv rau cov khoom siv hluav taws xob hloov hluav taws xob ntawm cov tshuab hluav taws xob hauv cov dej hauv cov reactor nuclear fais fab nroj tsuag. Nws yog lub hauv paus technology ntawm chav generators. Nws muaj kev tiv thaiv corrosion zoo heev, kub tsis kam thiab oxidation tsis kam.
GNEE muab Cov Phab Ntsa Thick Inconel 690 Yeeb Nkab nthuav qhia kev ruaj ntseg thiab cov khoom siv kho tshuab ntawm qhov kub thiab txias. Nws melting point yog hais txog 1330-1370 degree . Nws kuj muaj qhov zoo ntawm vuam kev ua tau zoo thiab tuaj yeem welded los ntawm ntau txoj kev vuam.
Inconel 690 seamless yeeb nkab specifications muaj li ntawm 6mm mus rau 630mm nyob rau hauv lub cheeb txoj kab uas hla thiab 0.3mm mus rau 100mm nyob rau hauv phab ntsa thickness, thiab nws muaj nyob rau hauv ntau yam ntaub ntawv xws li daim hlau, puag ncig tuav, thiab forging billets.
Cov ntaub ntawv khoom
Chemical Composition ntawm Cold Drawn Inconel 690 Pipe
| Qib | C | Mn | Mo | Co | Si | P | S | Ni | Cr | Fe | Al | Ti | Nb + Ta |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Ib 690 | 0.10 max | 0.50 max | 8.0 – 10.0 | max | 0.50 max | 0.015 max | 0.015 max | 58.0 feeb | 20.0 – 23.0 | 5. 0 max | 0.40 max | 0.40 max | 3.15 – 4.15 |
Lub cev muaj zog ntawm Thin Wall Inconel 690 Pipe
| Alloy 690 ntom, kg / dm3 | 8.19 |
| Permeability | 1.001 |
| Melting ntau yam, degree | 1343~1377 |
| Hluav taws xob tiv taus, μΩ•m | 1.148 |
| Thermal conductivity, W / m• degree | 13.5 |
| Poisson tus ration | 0.289 |
| Coefficient ntawm expansion(0 ~ 100 degree), ×10-6/ degree | 14.06 |
| Young Modulus, GPa | 211 |
Khoom Qhia
Inconel 690 Kub Exchanger Tube
Vim li cas thiaj xaiv GNEE
GNEE yog ib lub tuam txhab tshwj xeeb hauv kev tsim cov hlau stainless. Lub tuam txhab muaj cov cuab yeej siv niaj hnub no, thiab cov kab ntau lawm yog nruab nrog cov tshuab txias txias, cov tshuab txias dov, cov tshuab ncaj, cov khoom siv kuaj cov cav tov, eddy tam sim no flaw detectors, ultrasonic flaw detectors, lub cev thiab tshuaj lom neeg kuaj CS analyzers thiab lwm yam khoom siv thiab kuaj. .
Tiv tauj peb hnub no rau ib qho kev tsocai pub dawb, lossis xa ib qho kev nug nrog ua tiav cov cai rauss@gneesteel.com.
GNEE Factory Environment
GNEE packaging thiab Shipping
PRODUCTS TESTING
FAQ
Q. Koj yuav nkoj li cas thiab yuav siv sijhawm ntev npaum li cas thiaj tuaj txog?
A: Feem ntau nws yuav siv sijhawm 3-5 hnub los txog. Cua thiab hiav txwv shipping kuj xaiv tau. Rau cov khoom lag luam ntau, nws yog qhov zoo dua los xaiv kev xa khoom hiav txwv.
Q: Koj lub tuam txhab ua li cas hauv kev tswj kom zoo?
A: Lub Hoobkas kuaj daim ntawv pov thawj yog muab nrog cov khoom. Kev tshuaj xyuas thib peb lossis SGS tau txais yog tias tsim nyog.
Q: Kuv puas tuaj yeem luam kuv lub logo ntawm cov khoom?
A: Yog. Peb tuaj yeem muab OEM thiab ODM.
Cim npe nrov: inconel 690 alloy round kav, Tuam Tshoj inconel 690 alloy round kav lwm tus neeg
