Incoloy 800H (UNS N08810) muaj txwv cov ntsiab lus ntawm 0.05 txog 0.10%, uas yog nyob rau sab sauv ntawm Incoloy 800, thiab yog annealed ntawm 1149 txog 1177 degree ( Incoloy 800 yog annealed ntawm 983 txog 1038 degree). Cov kev sib txawv no qhia nws kom muaj kev ntxhov siab ntau dua thiab muaj zog dua li Incoloy 800.

Xa kev nug

Tsham tam sim no

Raws li tus neeg muag khoom thiab chaw tsim khoom nyob rau hauv Suav teb, GNEE Steel muab tus nqi -nickel zoo- raws li cov khoom siv alloy.

Xa E-mail:ss@gneesteel.com
Tel:+8615824687445

Khoom Taw qhia

Incoloy® alloys 80{{10}}H (UNS N08810) yog dual-certifiable Nickel-Iron-Chromium cov ntaub ntawv uas tiv taus oxidation, carburization thiab lwm yam kub corrosion . Cov tshuaj muaj pes tsawg leeg ntawm ob lub nickel alloys zoo ib yam rau Incoloy alloy 800 (UNS N08800), tshwj tsis yog cov qib siab dua ntawm cov pa roj carbon tam sim no hauv ob qib - (0.05-0.10%) hauv Incoloy alloy 800H, thiab (0.06-0.10%) ) nyob rau hauv Incoloy alloy 800HT. Incoloy alloy 800H muaj cov khoom zoo sib xws ntawm qhov kub siab tshaj 1100 degree F (600 degree).

Tshuaj ntsuam xyuas

Qhov hnyav % (tag nrho cov txiaj ntsig yog qhov siab tshaj plaws tshwj tsis yog muaj ntau yam qhia)

Lub ntsiab	800H
Nickel	300 feeb.-35.0 max.
Chromium	19. 0 min.-23 0 max.
Hlau	39.5
Cov pa roj carbon	0.05 feeb.-0.10 max.
Manganese	1.50
Phosphorus	0.045
Sulfur	0.015
Silicon	1.0
Aluminium	0.15 feeb.-0.60 max.
Titanium	0.15 feeb.-0.60 max.
Aluminium & Titanium	0.30 feeb.-1.20 max.

Mechanical Properties

Tus nqi zoo ntawm 70 degree F (21 degree)

Yield zog 0.2% Offset		Qhov kawg Tensile Lub zog		Elongation ua 2in.	Hardness
psi (min.)	(MPa)	psi (min.)	(MPa)	% (min.)	(max.)
29,000	200	77,000	531	52	126 Brinell

Incoloy material 800h

Txog Alloy 800H / Incoloy 800H / UNS N08810

Incoloy 800H yog ib qho tshuaj tiv thaiv muaj pes tsawg leeg ntawm Incoloy® alloy 800 (UNS N08800). Cov ntawv thov txuas ntxiv los ntawm petrochemical processing reformer raj mus rau refinery bellows thiab cov lus qhia flare. Lub zog tsim hluav taws xob, superheater thiab reheater raj kuj siv cov khoom siv. Thaum tshav kub kub kho stills, muffle furnace jigs thiab fixtures kuj siv cov khoom uas zoo heev.

Cov yam ntxwv ntawm Incoloy 800H

Siab kub lub zog
High creep rupture zog
Resistant oxidation thiab carburization nyob rau hauv qhov kub thiab txias
Zoo corrosion kuj nyob rau hauv ntau acidic ib puag ncig
Kev ua haujlwm zoo rau ntau cov huab cua uas muaj sulfur

Cov ntawv thov yog Incoloy 800H siv

Ethylene rauv quench boilers
Hydrocarbon tawg
Valves, fittings thiab lwm yam khoom raug corrosive nres los ntawm 1100-1800 degree F
Muaj cua sov
Cov khoom siv kho cua sov
Kev siv tshuaj thiab petrochemical
Super-heater thiab re-heaters nyob rau hauv fais fab nroj tsuag
Cov hlab ntsha siab
Kub exchangers

Pob & Xa

Incoloy steel 800h
