Aluminium alloy 2024
Raws li tus neeg muag khoom thiab chaw tsim khoom nyob rau hauv Suav teb, GNEE Steel muab tus nqi -nickel zoo- raws li cov khoom siv alloy.
- Xa E-mail:ss@gneesteel.com
- Tel:+8615824687445
Daim ntawv thov cov khoom siv aluminium
Aluminium Alloy 2024 video
Vim nws lub zog siab thiab qaug zog ua haujlwm, 2024 tau siv dav hauv cov dav hlau, tshwj xeeb tshaj yog cov tis thiab lub fuselage cov qauv hauv qab nro. Tsis tas li ntawd, vim tias cov khoom raug cuam tshuam rau thermal shock, 2024 yog siv los txheeb xyuas cov kua nkag mus rau sab nraum qhov kub thiab txias.
Aluminium Khoom Specification
| Khoom | 2024-T3 | 2024-T4 | 2024-T851 |
|---|---|---|---|
|
Qhov ntom |
2.78g / cm3 |
2.78g / cm3 |
2.78g / cm3 |
|
Tensile zog |
483 MPa ua |
469 MPa ua |
Tshaj 455 MPa |
|
Yield zog |
345 MPa rau |
324 MPa rau |
Tshaj 400 MPa |
|
Modulus ntawm elasticity |
73.1 gvp |
73.1 gvp |
72.4 gvp |
|
Brinell hardness - 500g hnyav, 10 mm pob |
120 |
120 |
128 |
|
Elongation ntawm tawg (12.7 hli xeem daim) |
18% |
19% |
5% |
|
Shear modulus |
28 GPA |
28 GPA |
27 GPA |
|
Shear zog |
283 gvp |
283 MPa ua |
296 gp ua |
|
qaug zog |
138 MPa rau |
138 MPa rau |
117 MPa |
|
Thermal expansion coefficient |
23.2 µm / m degree |
23.2 µm / m degree |
23.2 µm / m degree |
Aluminium alloy 2024
2024 aluminium alloy yog aluminium alloy nrog tooj liab ua lub ntsiab alloy. Nws yog siv nyob rau hauv daim ntawv thov xav tau ib tug siab zog-rau-qhov hnyav piv nrog rau zoo qaug zog kuj. Nws tuaj yeem tsuas yog welded los ntawm kev sib txhuam vuam thiab muaj qhov nruab nrab ua haujlwm. Vim tsis zoo corrosion kuj, txhuas los yog Al-1Zn cladding feem ntau yog siv los tiv thaiv, txawm hais tias qhov no yuav txo tau qaug zog. Nyob rau hauv lub qub nomenclature system, 2XXX series alloys tau hu ua duralumin thiab cov hlau no raug xaiv 24ST.
2024 feem ntau yog extruded thiab tseem muaj nyob rau hauv aluminized ntawv thiab phaj daim ntawv. Nws tsis zoo li ntawd (tab sis qhov cuam tshuam 2014 aluminium alloy yog).
Cov neeg siv khoom Case
neeg tuaj xyuas
FAQ
Q: Koj lub sijhawm xa khoom yog dab tsi?
A: Peb lub sijhawm khoom xa tuaj yog li ib lub lis piam, raws li tus naj npawb ntawm cov neeg siv khoom.
Q: Koj lub sijhawm xa khoom ntev npaum li cas?
A: Qhov no yog raws li qhov ntau. Feem ntau nws yog 30 hnub.
Q: Koj puas tuaj yeem muab cov qauv rau peb, puas yog dawb lossis nws puas yuav tsum tau them nyiaj?
A: Yog tias koj tsis tas yuav luam koj lub logo lossis lwm cov duab kos rau ntawm cov khoom, peb yuav tsis them tus nqi, tsuas yog qhia rau peb koj tus account freight, xws li Fedex, DHL, TNT. Yog tias koj tsis muaj, peb yuav tsum tau them tus nqi nthuav qhia kom tsim nyog.
Q: Hais txog tus nqi khoom ntawm Aluminium Alloy 2024?
A: Vim muaj kev hloov pauv hauv cov nqi raw khoom, cov nqi sib txawv nyob rau lub sijhawm sib txawv.
